Technical Parameter:
1 | Total Pressure | 8000KN |
2 | Board Size | 2440 *1220 mm |
3 | Feeding Direction | Transverse |
4 | Up Heating Platen Size | 1370*2700*52mm |
5 | Daylight Opening | 100 mm |
6 | Hot Press Layers | 10 |
7 | Hot Press Platen Quantity | 11 |
8 | Main Oil Cylinder | Φ 260 mm*1050mm x 6pcs |
9 | Main Oil Cylinder Working Stroke | 1000 mm |
10 | Small Lifting Cylinder | Ф120mm*1050mm*2pcs |
11 | Small Lifting Cylinder Stroke | 1000mm |
12 | Allowable Pressure | ≤25Mpa |
13 | Low Pressure Pump Flow | 75ml/r |
14 | Motor Power | 22kw |
15 | High Pressure Flow | 17ml/r |
16 | Power | 7.5kw |
17 | Allowable Pressure | ≤25Mpa |
18 | Closing Time with Loading | 10-15 s |
19 | Thickness of Frame Steel Platen | 35 mm |
20 | Structure | Combined Frame Structure |
21 | Main Motor Power | 18.5kw+7.5kw |
22 | Weight | Approx. 36 tons |
23 | Overall Dimension | 1370*3555*4200mm |
24 | Electrical Appliance Brand | Schneider |
25 | PLC Brand | DELTA (Taiwan brand)/Ucontrol |
26 | Origin of Cylinder | Wuxi |
27 | Pressure Gauge | Wuxi |
28 | Hydraulic Valve | PF-125 |
29 | Temperature Control System | (OPTIONAL) |
30 | Other Accessories | Like valves, pipes |
