Sanding Machine

12-01-2021

•
  •
  •
  •
  •

• Sanding Machine





  Technical Parameter:







  1	Product Name	Single-Head Widebelt Sander
  2	Model No.	LGNWD100-S1
  3	Working Width	40-1300mm
  4	Working Thickness	3-110mm
  5	Working Length	≥750mm
  6	Sand Belt Speed	23m/s
  7	Feeding Speed	10-70m/min
  8	Sand Belt Size	1330*2615mm
  9	Total Power	84.72kw
  10	Main Motor Power	75kw
  11	Working Pressure	0.55Mpa
  12	Compressed Air Consumption	0.1m³/min
  13	Air Suction Volumn	10000m³/h
  14	Overall Dimension	2190*3100*2300mm
  15	Net Weight	6.6Tons
